MA-QSFP-40G-SR-BD

Switch SFP Part MA-QSFP-40G-SR-BD-C is in UK stock and 100% Compatible with Cisco Meraki part MA-QSFP-40G-SR-BD.

Bi-Directional Transceiver Module
Tx Wavelength: Ch1:850nm; Ch2:900nm
Rx Wavelength: Ch1:900nm; Ch2:850nm
Media Type: Multi-Mode Fibre
TX Power -2.0~+4.0dBm
Max. Distance: 150m/OM4

Our compatible 40G Bidirectional transceiver matches the original Cisco specification and combines 4 x 10G lanes into 2 x 20 Gbps channels each transmitting and receiving simultaneously over two Multi mode fibre cores thereby delivering 40G total transmission. The module utilises 2 channels of 20G x VCSEL Laser transmitters at 850 nm and 20G x 900 nm receivers on each channel generating 40Gbps full duplex communication.

Connector Type_Dual LC, Data Rate_40G, Distance_150m, Fiber Mode_multimode, Transmission_850nm
Original price £315.00 - Original price £315.00
Original price
£315.00
£315.00 - £315.00
Current price £315.00

We back our products with a Lifetime Warranty as Standard

All products are covered with a lifetime replacement warranty and our 60 day NO QUIBBLE RETURN policy.

Product Specification Table

Compatible with Part Number:
MA-QSFP-40G-SR-BD
Form Type:
QSFP+
Data Rate:
40G
Wavelength:
850nm
Distance:
150m
Connector:
Dual LC
Fiber Type:
multimode
Operating Temperature:
0~70 C
DOM Supported:
Yes
4 x 10G lanes
over 2 x20 Gbps channels MMF

All our transceivers are MSA form factor specification and configured in-house by our engineers to initialise and perform exactly as the OEM equivalent.
