QSFP-DD-800G-SR8

by Cisco
$3,977.00

Free UK delivery on all orders

We back our products with a Lifetime Warranty as Standard

All products are covered with a lifetime replacement warranty and our 60 day NO QUIBBLE RETURN policy.

Switch SFP Part QSFP-DD-800G-SR8-C is in UK stock and 100% Compatible with Cisco part QSFP-DD-800G-SR8. 800GBASE Ethernet throughput up to 100m over Multimode fiber (MMF) with MPO-16 connectors.

This module supports 16 electrical interface channels (8 pairs) that operate as 800G Ethernet links for Data Center, Breakout 8 x 100G DR application. This transceiver is compliant with IEEE P802.3ck, IEEE 802.3cu, QSFP-DD MSA. The built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters.


The multiplexing and demultiplexing of 16 wavelengths in 8 pairs and are managed within the device and connect 800G signals from the server side (NIC) to the data center aggregation switch.

Connector Type_MPO, Data Rate_800G, Distance_100m, Fiber Mode_Multimode, Transmission_850nm
Compatible with Part Number:
QSFP-DD-800G-SR8
Form Type:
QSFP DD
Data Rate:
800G
Wavelength:
850nm
Distance:
100m
Connector:
MTP/MPO-16
Fiber Type:
Multimode
Operating Temperature:
0~70 C
DOM Supported:
Yes
8x 100G
Breakout for Higher Port Density
Compliant with IEEE P802.3ck, IEEE 802.3cu, QSFP-DD MSA
Compliant with IEEE P802.3ck, IEEE 802.3cu, QSFP-DD MSA
8 channels full-duplex transceiver module
8 channels full-duplex transceiver module
